SKX-S-LD-YT2017 15W-60W All-in-One Solar Street Light with Microwave Sensor

SKX-S-LD-YT2017 15W-60W all-in-one solar street light with LiFePO4 battery and microwave sensor

P/N: SKX-S-LD-YT2017

15W-60W

All-in-One Solar Street Light

LiFePO4 Battery

Microwave Sensor

12h Daily Lighting

3-Day Backup

SKX-S-LD-YT2017 15W-60W All-in-One Solar Street Light with Microwave Sensor

The SKX-S-LD-YT2017 is an all-in-one solar street light series covering 15W to 60W. The solar panel, LED light source, LiFePO4 battery and microwave sensing controller are integrated into one compact aluminum alloy housing. It is designed for standalone outdoor lighting applications including residential roads, rural roads, pedestrian paths, commercial areas and other off-grid lighting projects.

The series includes seven standard configurations from 15W to 60W, with different solar panel and battery capacities to match different installation heights and lighting requirements.

Key Features

All-in-One Design: Solar panel, LED module, LiFePO4 battery and microwave sensing controller are integrated into one compact unit.
12-Hour Lighting: Standard lighting schedule is 4 hours at 100% power followed by 8 hours at 50% power.
Multiple Power Options: Seven configurations from 15W to 60W are available for different installation heights and road lighting requirements.
Flexible Installation: Sleeve-type mounting with three rear mounting configurations for different pole installation conditions.

SKX-S-LD-YT2017 Specifications

Specification	15W	20W	25W	30W	40W	50W	60W
Model	SKX-S-LD-YT2017-15W	SKX-S-LD-YT2017-20W	SKX-S-LD-YT2017-25W	SKX-S-LD-YT2017-30W	SKX-S-LD-YT2017-40W	SKX-S-LD-YT2017-50W	SKX-S-LD-YT2017-60W
Housing Material	6063 Aluminum Alloy
LED Power	15W	20W	25W	30W	40W	50W	60W
Solar Panel	18V 30W	18V 40W	18V 50W	18V 60W	18V 80W	18V 90W	18V 100W
LiFePO4 Battery	12V 15Ah (180Wh)	12V 18Ah (216Wh)	12V 22Ah (264Wh)	12V 28Ah (336Wh)	12V 35Ah (420Wh)	12V 45Ah (540Wh)	12V 55Ah (660Wh)
Daily Lighting Time	12h
Standard Lighting Mode	4h at 100% Power + 8h at 50% Power
Recommended Installation Height	3-4m	4-5m	5-6m	5-6m	6-8m	6-8m	8-10m
Rainy-Day Backup	3 Days
Charging Time	5-6h
Luminous Flux	2200-2400lm	3000-3200lm	3750-4000lm	4500-4800lm	6000-6400lm	7500-8000lm	9000-9300lm
Product Dimensions	525×385×150mm	685×385×150mm	885×385×150mm	990×385×150mm	1305×385×150mm	985×540×150mm	1305×540×150mm
Certifications	CE / RoHS / LM-79
Warranty	3 Years
Light Source Lifetime	100,000h

Lighting Control

The standard YT2017 lighting program provides 12 hours of daily operation, with 100% power during the first 4 hours and 50% power during the following 8 hours. The integrated microwave sensing controller can also be used according to the project control requirements.

Lighting hours, power levels, dimming periods and sensing control can be reviewed for customized projects.

Customized Solar Street Light Configuration

The standard YT2017 models provide a starting configuration for different installation heights and lighting requirements. FORLEAVES can also review customized configurations according to customer project requirements.

LED power
Solar panel wattage
LiFePO4 battery capacity
Daily lighting hours
Full-power and reduced-power periods
Dimming level
Microwave sensing control
Color temperature
Housing color
Customer logo
Mounting configuration

For a customized project, customers can provide the installation location, mounting height, required LED power, daily operating hours, preferred control method, battery backup requirement and estimated quantity. FORLEAVES can review the solar panel, battery and lighting configuration accordingly.

Installation

The SKX-S-LD-YT2017 uses sleeve-type mounting and provides three rear mounting configurations to accommodate different solar street light pole and installation conditions.

Applications

Urban and residential roads
Rural and village roads
Pedestrian and non-motorized vehicle paths
Commercial streets
Parking areas
Industrial and public areas
Garden and landscape areas
Remote and off-grid lighting projects

Related All-in-One Solar Street Lights

FORLEAVES offers different all-in-one solar street light configurations for various power levels, installation conditions and control requirements.

Frequently Asked Questions

Q1: What is the SKX-S-LD-YT2017?
A1: It is an all-in-one solar street light series integrating the solar panel, LED light source, LiFePO4 battery and microwave sensing controller.

Q2: What power options are available?
A2: The YT2017 series covers 15W, 20W, 25W, 30W, 40W, 50W and 60W.

Q3: How many hours does it operate each night?
A3: The standard lighting program is 12 hours per day: 4 hours at 100% power followed by 8 hours at 50% power.

Q4: Can the lighting schedule be customized?
A4: Yes. Lighting hours, power levels, dimming periods and control methods can be reviewed according to project requirements.

Q5: Can the battery capacity be customized?
A5: Yes. The LiFePO4 battery capacity can be reviewed according to the required lighting load, operating hours and project conditions.

Q6: Can the solar panel wattage be customized?
A6: Yes. Solar panel capacity can be reviewed according to the LED power, battery capacity and local solar conditions.

Q7: Does the YT2017 use a microwave sensor?
A7: Yes. The product integrates a microwave sensing controller.

Q8: What type of battery is used?
A8: The YT2017 uses a LiFePO4 lithium battery, with capacities from 12V 15Ah to 12V 55Ah across the standard models.

Q9: How many rainy days of backup are specified?
A9: The supplied specification lists 3 days of rainy-day backup for the standard YT2017 configurations.

Q10: What is the recommended installation height?
A10: Depending on the model, the recommended installation height ranges from approximately 3-4m to 8-10m.

Q11: What certifications are available?
A11: The supplied specification lists CE, RoHS and LM-79.

Q12: What is the warranty period?
A12: The stated warranty period is 3 years.

Q13: What packaging is used for the solar street light?
A13: Export packaging is used for transportation. Packaging can be reviewed according to order quantity and shipping requirements, and reinforced or wooden-crate packaging can be considered for project shipments.

Q14: Can FORLEAVES provide customized solar street lights?
A14: Yes. FORLEAVES can review LED power, solar panel wattage, battery capacity, lighting schedule, dimming level, control method, housing color, logo and mounting configuration according to customer requirements.

Q15: What information is needed for a customized project?
A15: Useful information includes project location, installation height, LED power, daily lighting hours, lighting schedule, control method, battery backup requirement and estimated quantity.

15W-60W All-in-One Solar Street Light for Outdoor Projects

The SKX-S-LD-YT2017 provides seven all-in-one solar street light configurations from 15W to 60W, combining solar charging, LiFePO4 battery storage, LED lighting and microwave sensing control in one integrated unit.

With different solar panel and battery capacities, multiple installation heights and flexible lighting control options, the YT2017 series can be used as a standard product platform or reviewed for customized solar street light projects.

Looking for an all-in-one solar street light for your project?
Send us your project location, installation height, required LED power, daily lighting hours, preferred control method and quantity. FORLEAVES can review the solar panel, LiFePO4 battery and lighting configuration according to your project requirements.
